Number Of Effective Pixels
26.1 millions pixels
Image Sensor
23.5mm x 15.6mm (APS-C) X-Trans CMOS 4 with primary color filter.
Storage Media
SD memory card (-2GB) / SDHC memory card (-32GB) / SDXC memory card (-512GB) UHS-I*1
File Format Of Still Image
Compliant with Design rule for Camera File system (DCF2.0) JPEG: Exif Ver 2.3
RAW: 14bit RAW (RAF original format) / RAW+JPEG
Number Of Recorded Pixels
L: <3:2> 6240 x4160 / <16:9> 6240 x3512 / <1:1> 4160 x4160 M: <3:2> 4416 x2944 / <16:9> 4416 x2488 / <1:1> 2944 x2944 S: <3:2> 3120 x2080 / <16:9> 3120 x1760 / <1:1> 2080 x2080 Panorama:
L: 2160 x 9600 [Horizontal : 9600 x 1440] M: 2160 x 6400 [Horizontal : 6400 x 1440]
Lens Type
FUJINON single focal length lens
Lens Focal Length
f=23mm (35mm format equivalent : 35mm)
Lens Max.
Aperture F2.0
Lens Configuration
8 elements in 6 groups (includes 2 aspherical elements)
Lens Nd Filter
Yes (4 stops)
Aperture
F2 – F16 1/3EV step (controlled with 9-blade aperture diaphragm)
Focus Range
Approx. 10cm to infinity / 3.9in. to infinity
Conversion Lens
WIDE / TELE / OFF
Digital Tele-Converter
35mm (Nomal), 50mm, 70mm, 35mm fomat equivalent
Sensitivity Standard Output
AUTO1 / AUTO2 / AUTO3 / ISO160-12800 (1/3EV step)
Sensitivity Extended Output
ISO80 / 100 / 125 / 25600 / 51200
Exposure Control
TTL 256-zone metering, Multi / Spot / Average/ Center Weighted
Exposure Mode
P (Program AE) / A (Aperture Priority AE) / S (Shutter Speed Priority AE) / M (Manual Exposure)
Exposure Compensation
-5.0EV-+5.0EV 1/3EV step (Movie: -2.0EV-+2.0EV)
Shutter Type
Lens Shutter
Shutter Speed
Mechanical Shutter:
P mode: 4sec. to 1/4000sec
A mode: 30sec. to 1/4000sec, S/M mode: 15min. to 1/4000sec Bulb mode: up to 60min.
Electronic Shutter:
P mode: 4sec. to 1/32000sec
A mode: 30sec. to 1/32000sec, S/M mode: 15min. to 1/32000sec Bulb mode: 1sec. Fixed
Mechanical+Electronic Shutter:
P mode: 4sec. to 1/32000sec
A mode: 30sec. to 1/32000sec, S/M mode: 15min. to 1/32000sec Bulb mode: up to 60min.
Continuous Shooting
Approx. 11fps (JPEG: 38 frames, Lossless compression RAW: 17 frames, Uncompressed RAW: 17 frames)
Approx. 8.0fps (JPEG: 76 frames, Lossless compression RAW: 18 frames, Uncompressed RAW: 18 frames)
Approx. 6.0fps (JPEG: 220 frames, Lossless compression RAW: 21 frames, Uncompressed RAW: 18 frames)
Approx. 5.0fps (JPEG: 458 frames, Lossless compression RAW: 24 frames, Uncompressed RAW: 19 frames)
Continuous Shooting (Contd.)
Approx. 4.0fps (JPEG: endless, Lossless compression RAW: 28 frames, Uncompressed RAW: 20 frames)
Approx. 3.0fps (JPEG: endless, Lossless compression RAW: 34 frames, Uncompressed RAW: 21 frames)
Approx. 30fps [Only electronic shutter, 1.25 x Crop] (JPEG: 29 frames, Lossless compression RAW: 17 frames, Uncompressed RAW: 17 frames)
Continuous Shooting (Contd..)
Approx. 20fps [Only electronic shutter, 1.25 x Crop ] (JPEG: 79 frames, Lossless compression RAW: 17 frames, Uncompressed RAW: 17 frames)
Approx. 20fps [Only electronic shutter] (JPEG: 32 frames, Lossless compression RAW: 17 frames, Uncompressed RAW: 17 frames)
Approx. 10fps [Only electronic shutter, 1.25 x Crop] (JPEG: 153 frames, Lossless compression RAW: 18 frames, Uncompressed RAW: 18 frames)
Continuous Shooting (Contd…)
Approx. 10fps [Only electronic shutter] (JPEG: 81 frames, Lossless compression RAW: 18 frames, Uncompressed RAW: 18 frames)
Approx. 8.0fps [Only electronic shutter, 1.25 x Crop] (JPEG: 90 frames, Lossless compression RAW: 18 frames, Uncompressed RAW: 18 frames)
Recordable frames depends on recording media
Speed of continuous shooting depends on shooting environment and shooting frames Auto Bracketing
AE Bracketing
(Frames: 2, 3, 5, 7, 9 Step: by 1/3EV step, up to +/-3EV steps)
Filmsimulation bracketing (Any 3 types of film simulation selectable) Dynamic Range Bracketing (100%, 200%, 400%)
ISO sensitivity Bracketing ( +/-1/3EV, +/-2/3EV, +/-1EV)
White Balance Bracketing ( +/-1, +/-2, +/-3) Focus Bracketing (AUTO, MANUAL)
Af Mode
Single AF / Continuous AF / MF
Af Type
Intelligent Hybrid AF (TTL contrast AF / TTL phase detection AF)
Af Low-Light Performance Contrast: -2.0EV
Phase Detection: -5.0EV Af Frame Selection
Single point AF: EVF / LCD: 13 x9 / 25 x17 (Changeable size of AF frame) Zone AF: 3 x3 / 5 x5 / 7 x7 from 117 areas on 13 x9 grid
Wide/Tracking AF: (up to 18 area)
White Balance
Automatic Scene recognition / Custom1-3 / Color temperature selection (2500K-10000K) / Preset: Daylight, Shade,
Self-Timer
10sec. / 2sec.
Interval Timer Shooting
Yes (Setting: Interval, Number of shots, Starting time)
Flash
Auto flash [Super Intelligent Flash] Effective range: (ISO 1600) approx. 1.0 – 24.3′ (30cm – 7.4m) Guide Number: approx. 4.4 (ISO100 m)
Flash Mode
TTL MODE (Flash Auto, Standard, Slow Sync.), Manual, Commander, OFF
Flash Sync. Mode
1st Curtain, 2nd Curtain
Flash Red Eye Removal
Flash + Removal, Flash, Removal, Off
Hot Shoe
Yes (Dedicated TTL Flash compatible)
Ovf
Reverse Galilean viewfinder with electronic bright frame display Coverage of frame area v.s. capturing area:
approx. 95%
Magnifications approx x0.52″
Evf
0.5 inch approx. 3.69 millions dots OLED Color Viewfinder (4:3)
Coverage of viewing area vs. capturing area: approx. 100%
Eyepoint: approx. 16.8mm (from the eyepiece lens), Diopter adjustment: -4-+2m-1 Magnification: 0.66 x with 50mm lens (35mm equivalent) at infinity and diopter set to -1m- 1
Diagonal angle of view: approx. 32 Degree (Horizontal angle of view: approx. 27 Degree ) Built-in eye sensor
Lcd Monitor
3.0 inch, aspect ratio 3:2
approx.1.62 millions dots tilting touch screen color LCD monitor(approx. 100% coverage) File Format
Format: MOV, Compression: MPEG-4 AVC/H.264
Audio: Linear PCM / Stereo sound 2ch / 24bit / 48KHz sampling
Movie File Size/Frame Rate/Rec. Time
[DCI 4K (4096 x2160)] 29.97p/25p/24p/23.98p, 200Mbps/100Mbps, up to approx. 10min [4K (3840 x2160)] 29.97p/25p/24p/23.98p, 200Mbps/100Mbps, up to approx. 10min [Full HD (2048 x1080)] 59.94p/50p/29.97p/25p/24p/23.98p, 200Mbps/100Mbps/50Mbps, up to approx. 15min.
[Full HD (1920 x1080)] 59.94p/50p/29.97p/25p/24p/23.98p, 200Mbps/100Mbps/50Mbps,
up to approx. 15min.
File Size/Frame Rate/Rec. Time (Contd.)
[Full HD (1920 x1080) High speed rec.] 120p/100p, 200Mbps(recording), up to approx. 6min.
For recording movies, use a SD memory card with UHS Speed Class 3 or higher. Although movie recording will continue without interruption when the file size reaches 4GB, subsequent
Film Simulation Mode
17 modes (PROVIA/Standard, Velvia/Vivid, ASTIA/Soft, Classic Chrome, PRO Neg.Hi, PRO Neg.Std, Black & White, Black & White+Ye Filter, Black & White+R Filter, Black & White+G Filter, Sepia, ACROS, ACROS+Ye Filter, ACROS+R Filter, ACROS+G Filter, ETERNA/Cinema, Classic Neg) Monochromatic Color
Clarity Setting +/-5 steps
Hdr Mode
AUTO, 200%, 400%, 800%, PLUS
Grain Effect
Roughness: Strong, Weak, Off / Size: Large, Small
Color Chrome Effect Strong, Weak, Off
Color Chrome Blue Strong, Weak, Off
Dynamic Range Setting
Still: AUTO, 100%, 200%, 400%
ISO restriction (DR100%: No limit, DR200%: ISO320 or more, DR400%: ISO640 or more) Movie: 100%, 200%, 400%
ISO restriction (DR100%: No limit, DR200%: ISO320 or more, DR400%: ISO640 or more)
Advanced Filter
Toy camera, Miniature, Pop color, High-key, Low-key, Dynamic tone, Soft focus, Partial color (Red / Orange / Yellow / Green / Blue / Purple)
Wireless Transmitter
Standard Access Mode: Infrastructure
Wireless Transmitter Standard
IEEE802.11b/g/n (standard wireless protocol)
Wireless Transmitter Standard Encryption WEP / WPA / WPA2 mixed mode
Bluetooth Standard
Bluetooth Ver 4.2 (Bluetooth low energy)
Bluetooth Operating Frequency
2402 – 2480MHz (Center Frequency)
Terminal Digital Interface
USB Type-C (USB3.1 Gen1)
Terminal Hdmi Output
HDMI Micro connector (Type D)
Terminal Other
Microphone / shutter release input: 2.5mm
NP-W126S Li-ion battery (included)
Battery Life
For Still Images: Approx. 350 / 420 frames (EVF / OVF Normal Mode)
Actual Battery Life Of Movie Capture
[4K] approx. 45min. (29.97p)
[Full HD] approx. 50min. (59.94p) Continuance Battery Life
Movie Capture: [4K] approx. 50min. (29.97p)
[Full HD] approx. 75min. (59.94p)
Operating Temperature
0 Degree C-+40 Degree C Operating Humidity
10%-80% (no condensation)
Starting Up Period
Approx. 0.5sec.
Dimensions (H x W x D)
74.8 x 128.0 x 53.3mm
(Minimum depth 32.7mm)
Weight
Approx. 478g (including battery and SD memory card) Approx. 428g (excluding battery and SD memory card)
